WF275BD01
6 left in stock
Wavecor WF275BD01, 275mm (11in) Paper / Glass Fiber Cone Woofer, with 39mm Voice Coil, 4ohm.
CA$351.12Each
- WF275BD01
- WAVECOR
Wavecor WF275BD01, 275mm (11in) Paper / Glass Fiber Cone Woofer, with 39mm Voice Coil, 4ohm.
| Product Specifications | |
|---|---|
| Manufacturer | WAVECOR |
| Speaker Type | Glass Fiber/Paper Cone Woofer |
| Nominal Diameter | 28cm |
| Impedance | 4 ohms |
| Power Handling (RMS) | 180 W |
| Frequency Response | 27-1500 Hz |
| Sensitivity | 90 dB |
| Voice Coil Diameter | 39mm |
The 10.75” transducers WF275BD01 (4 ohm) and WF275BD02 (8 ohm) were designed as high performance bass/midrange units for monitors and high-end hi-fi speakers. They offer outstanding extended bass performance and overall dynamic and detailed reproduction.
Ideal for multi-way constructions they additionally offer designers the rare opportunity of working with 10” 2-way solutions if paired with a suitable tweeter, like for instance some of the Wavecor 30 mm units.
Features
- Balanced Drive motor structure for optimal drive force symmetry resulting in largely reduced even order harmonic distortion
- Copper cap on center pole to reduce voice coil inductance and to minimize variations in voice coil inductance as a function of voice coil position
- Cone made of a new paper/glass fiber mix with improved consistency and stability
- Rigid die cast alu chassis with extensive venting for lower air flow speed reducing audible distortion
- Vented voice coil former for reduced distortion and compression
- Heavy-duty black fiber glass voice coil former to reduce mechanical losses resulting in better dynamic performance and low-level details
- Large motor with 39 mm voice coil diameter for better control and power handling
- Built-in alu field-stabilizing ring for reduced distortion at high levels
- Low-loss suspension (high Qm) for better reproduction of details and dynamics
- Black plated motor parts for better heat transfer to the surrounding air
- Conex spider for better durability under extreme conditions
- Gold plated terminals to ensure long-term trouble free connection
| FILENAME | ACTION |
|---|---|
| WF275BD01_02.pdf | Download |
